engine light 3rd gen auto- what could it be?

91pREluDe · Post by **91pREluDe** » Thu Mar 20, 2014 3:37 pm

I am and blinks coming from ecu second photo (small window).... Engine light doesn't blink.

Post by **NafemanNathan** » Thu Mar 20, 2014 3:41 pm

It's just strange that 10 quick blinks is 10 and that should just be one long blink. And I don't know what fault code 70 is.

91pREluDe · Post by **91pREluDe** » Thu Mar 20, 2014 3:57 pm

Or it might be code 6 and code 10... Whitch is weird...

Post by **NafemanNathan** » Thu Mar 20, 2014 4:01 pm

Are you able to take a video of the flashes?

You're looking for any of these numbers...

'88-91' PGMFI OBD 0

Code 0 ECU
Code 1 Oxygen content A
Code 2 Oxygen content B
Code 3 MAP sensor
Code 4 Crank angle sensor
Code 5 MAP sensor
Code 6 Coolant temperature
Code 7 TPS sensor
Code 8 TDC position sensor
Code 9 No.1 cylinder position sensor
Code 10 Intake air temperature sensor
Code 11
Code 12 Exhaust gas recirculation system
Code 13 Atmospheric pressure sensor
Code 14 Electronic idle control
Code 15 Ignition output signal
Code 16 Fuel injector
Code 17 Vehicle speed sensor

'90-'91 PGM-FI

Code 0 ECU
Code 1 Oxygen content A *, Oxygen content **
Code 2 Oxygen Content B
Code 3 MAP sensor
Code 4 Crank angle sensor
Code 5 MAP sensor
Code 6 Coolant temperature
Code 7 Throttle position sensor
Code 8 TDC position sensor
Code 9 No.1 cylinder position sensor
Code 10 Intake air temperature sensor
Code 11
Code 12 Exhaust gas recirculation system
Code 13 Atmospheric pressure sensor
Code 14 Electronic air control
Code 15 Ignition output signal
Code 16 Fuel injector
Code 17 Vehicle speed sensor
Code 41 ** Oxygen sensor heater
Code 43 ** Fuel supply system

* 2.0 liter engines
** 2.1 liter engines

91pREluDe · Post by **91pREluDe** » Thu Mar 20, 2014 4:58 pm

Here is the video...
@nafemannathan

Post by **NafemanNathan** » Thu Mar 20, 2014 8:18 pm

That's 6 and then 10 bud, so...

Code 6 Coolant temperature

Code 10 Intake air temperature sensor

Post by **Lude-dude** » Fri Mar 21, 2014 10:00 am

If you remove the sensors be careful they go brittle and generally fall apart

91pREluDe · Post by **91pREluDe** » Fri Mar 21, 2014 12:51 pm

Cheers guys will try to sort it out, but that doesnt explain my Speedo

I think before I got the lude guy changed the battery

Post by **NafemanNathan** » Fri Mar 21, 2014 1:00 pm

91pREluDe wrote:Cheers guys will try to sort it out, but that doesnt explain my Speedo

I think because it didn't flash up a code 17 (Vehicle speed sensor), it goes to suggest it's more than likely your actual clocks (or at least the connection/wiring to it.
