Hub swap???!

bb4life · Post by **bb4life** » Mon Aug 12, 2013 6:59 pm

Evening all! Would it be possible to swap the hubs on my 4th gen for 5th gen ones?! As ive got some 5 stud rims which i want on my lude, or would it be better to get hub adaptors made?! Thanks fred

Post by **NafemanNathan** » Mon Aug 12, 2013 7:49 pm

Indeed it is bud

It's a straight swap, but you need to make up washers to pack out the driveshafts on the front.

106pete · Post by **106pete** » Mon Aug 12, 2013 8:04 pm

I've done mine aswell, just get 5g driveshafts and its a straight swap

bb4life · Post by **bb4life** » Mon Aug 12, 2013 9:13 pm

Cushty! Is anyone breaking a 5thgen?

Post by **NafemanNathan** » Mon Aug 12, 2013 9:18 pm

Checked the breaking section?

bb4life · Post by **bb4life** » Mon Aug 12, 2013 10:59 pm

I will try it, if anyone has any ill come grab them!

Fons[DutchGuy] · Post by **Fons[DutchGuy]** » Tue Aug 13, 2013 6:12 pm

Do you need the drive shaft with a 5th 2.0i? And how much would a set of hubs cost? Just checking, I might do it when I finaly pick up my car..

K30DPC · Post by **K30DPC** » Thu Aug 15, 2013 6:24 am

My cost me about £100 inc postage. I get them from ebay and bloke who sell them had another set. I also get all four abs sensors which are needed. They are differently mounted to the hubs. I used my ori driveshafts and I don't think U really need ones from V gen. U only have to find somebody who will make a washer for U and put it under that big nut which keeps outer CV joint into the hub. Washer have to be 32mm ID, 42-45mm OD and 3mm thick. And it works

I hope I wrote it clearly.

Post by **rob quilter** » Thu Aug 15, 2013 9:21 am

Just thought I'd point out 2.0 5th gens are 4 stud, 2.2 5th gens are 5 stud.

Post by **NafemanNathan** » Thu Aug 15, 2013 9:28 am

I think that's why Fons was asking whether he'd have the spacing issue if he converted to 5 bolt Rob... Because you'd think his driveshafts would already be the correct length for a 5 bolt conversion and wouldn't require the spacer
